Scott Passage 20 Wave 2026 - Electric Hybrid Bike
Handling is also light and easy, feeling more like a traditional bike than cumbersome and sluggish compared to a heavier urban E-Bike. The motor unit is just 2kg, low in the frame, and compact enough to provide confidence when navigating and a more natural pedaling style thanks to its favorable Q-factor.
We equipped this Passage 20 with a 75mm suspension fork to soften rough pavement on your routes and 45mm tires to add stability and durability no matter what comes your way. Its 9-speed drivetrain gives you the gearing range to ride around town like a pro, and the rear rack sets you up to stow the day’s essentials.
Please note that bike specifications are subject to change without prior notice.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Alloy S-L=29", 6061 Alloy custom butted tubing, Top extraction battery |
| Fork | SR Suntour NRX32-E Air LO R, Tapered , 15x100 bolt Axle, Remote Lock Out , Steel Steerer, 75mm Travel |
| Headset | Acros, 1.5"- 1.5", semi integ. OD 50/61mm, ID 44/55mm |
| Bars | Syncros Welded Alloy Combo 680mm, Backsweep 9°, Upsweep 8°, 70mm, with front Light mount |
| Front Brake | Shimano BR-MT200 Disc |
| Rear Brake | Shimano BR-MT200 Disc |
| Rear Mech | Shimano CUES RDU4000GS 9 Speed |
| Shifters | Shimano CUES SLU4009RC, 9 Speed |
| Speed | 9 |
| Rims | Syncros X15 Disc |
| Front Hub | Shimano HBTC50015B CL, 15x100mm |
| Rear Hub | Shimano FHTC500HMB CL, 12x142mm |
| Spokes | Black Spokes |
| Front Tyre | Schwalbe G-One Overland 365 Performance, 700x45C |
| Rear Tyre | Schwalbe G-One Overland 365 Performance, 700x45C |
| Seat Post | Syncros M3.0, 31.6 |
| Saddle | Syncros Capilano |
| Chainset | FSA CK-220 170mm |
| Chain | Shimano LG500 |
| Cassette | Shimano LG300, 11-46T |
| Battery Size (WH) | Compact Tube 400Wh |
| Motor | Bosch Performance Line SX (BDU314Y) |
| User Interface | Bosch Purion 200 |
