Trek Fuel EXe 5 2025 - Electric Mountain Bike
The Fuel EXe 5 blends confident trail geometry with natural-feeling e-assist, giving you extra power on climbs without losing the flow on descents.
Key Features:
- Alpha Platinum Aluminium frame with Mino Link, ABP & 140 mm travel
- RockShox Recon Silver RL fork with 150 mm travel
- X-Fusion Pro 2 rear shock, 140 mm travel
- Shimano Deore M6100 12-speed drivetrain
- Tektro HD-M745 4-piston hydraulic disc brakes
- 29" Bontrager Line TLR wheels with XT3 Elite 2.4" tyres
- TranzX dropper post, 150 mm travel
- Available with 0% APR finance
Drive Information:
- Motor: TQ-HPR50 mid-drive, 50 Nm torque
- Battery: 360 Wh removable battery
- User Interface: TQ LED display with Bluetooth & ANT+
The Trek Fuel EXe 5 bridges the gap between traditional trail bikes and e-mountain bikes. It keeps the lively, responsive feel of a classic full-suspension mountain bike while adding smooth, quiet electric support that feels completely natural.
Natural Power, Seamless Ride
At the heart of the Fuel EXe 5 is the TQ-HPR50 motor — a compact, lightweight drive unit delivering 50 Nm of torque. Using a harmonic pin-ring transmission rather than bulky gears or belts, it’s almost silent and provides an incredibly smooth, natural pedalling experience. The 360 Wh battery is cleanly integrated into the downtube yet easy to remove for convenient charging, offering 2–5 hours of riding time.
If you want to go further, an optional 160 Wh TQ HPR Range Extender fits neatly in a standard bottle cage, boosting range by up to 40% without adding unnecessary bulk.
Smart Connectivity and Control
The TQ LED display is compact and easy to read, giving you all the key ride stats at a glance. With Bluetooth and ANT+ connectivity, it links seamlessly to the Trek Central app, allowing you to fine-tune motor settings, track rides, check battery status and even access real-time range calculations and navigation features.
Trail-Ready Design and Handling
Built from Alpha Platinum Aluminium, the frame uses Trek’s Mino Link system to adjust geometry between slacker or steeper head angles, while ABP (Active Braking Pivot) keeps suspension active and controlled even under braking. The RockShox Recon Silver RL fork offers 150 mm of travel, and the X-Fusion Pro 2 shock provides 140 mm at the rear — perfect for tackling technical trails and flowing descents with confidence.
A Shimano Deore M6100 12-speed drivetrain delivers smooth, precise shifting, and the Tektro HD-M745 4-piston brakes offer consistent stopping power on demanding terrain. Rolling on Bontrager Line TLR 29" wheels wrapped in XT3 Elite 2.4" tyres, this bike balances grip, speed and stability for all-day trail performance.
Fine Details that Matter
A TranzX dropper post with 150 mm travel adds control on descents, while a Bontrager Arvada saddle ensures comfort over long rides. The bike’s internal cable routing keeps the setup neat and protected from trail debris, and Boost148 rear spacing increases stiffness for precise handling.
With its balanced geometry, refined power delivery and trail-focused design, the Trek Fuel EXe 5 is for riders who love the feel of a traditional trail bike — just with that little extra boost when the climb gets tough.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Alpha Platinum Aluminium, removable battery, internal routing, alloy rocker link, 34.9 mm seat tube, upper chain guide mount, 55 mm chain line, Mino Link, ABP, Boost148, UDH, 140 mm travel |
| Fork | Rockshox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 offset, Boost110, 15 mm Maxle Stealth, 150 mm travel |
| Rear Shock | X-Fusion Pro 2, 2-position damper, 205 mm x 60 mm |
| Stem | Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
| Bars | Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width |
| Front Brake | Tektro HD-M745 4-piston hydraulic disc |
| Rear Brake | Tektro HD-M745 4-piston hydraulic disc |
| Rear Mech | Shimano Deore M6100, long cage |
| Shifters | Shimano Deore M6100, 12-speed |
| Speed | 12 |
| Rims | Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve |
| Front Hub | Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| Rear Hub | Bontrager alloy, loose bearing, alloy axle, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle |
| Front Tyre | Bontrager XT3 Elite, wire bead, 60 tpi, 29 x 2.40" |
| Rear Tyre | Bontrager XT3 Elite, wire bead, 60 tpi, 29 x 2.40" |
| Seat Post | TranzX JD-YSI-22PLQ, 150 mm travel, internal routing, 34.9 mm |
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
| Chainset | E*thirteen E*spec Plus, 165 mm length |
| Chain | Shimano Deore M6100, 12-speed |
| Cassette | Shimano Deore M6100, 10-51, 12-speed |
| Battery Size (WH) | TQ 360Wh |
| Motor | TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power |
| User Interface | TQ LED display with Bluetooth & ANT+ connectivity |
Trek Fuel EXe 2025 Size Chart
| Size | Height cm | Height Feet / Inches | Inseam cm | Inseam Inches |
|---|---|---|---|---|
| S | 155 - 165 cm | 5'1" - 5'5" | 74 - 78 cm | 29" - 31" |
| M | 165 - 177 cm | 5'5" - 5'10" | 79 - 83 cm | 31" - 33" |
| L | 177 - 188 cm | 5'10" - 6'2" | 84 - 89 cm | 33" - 35" |
| XL | 188 - 195 cm | 6'2" - 6'5" | 89 - 91 cm | 35" - 36" |
What size frame do I need if I am between sizes? - read here
Trek Fuel Exe 2025 Geometry Chart
| Size | S | M | L | XL | ||||
|---|---|---|---|---|---|---|---|---|
| High | Low | High | Low | High | Low | High | Low | |
| Stack | 616 | 620 | 625 | 629 | 625 | 629 | 634 | 638 |
| Reach | 434 | 428 | 459 | 453 | 489 | 483 | 514 | 508 |
| Head Tube Length | 100 | 100 | 110 | 110 | 110 | 110 | 120 | 120 |
| Head Tube Angle | 65.3° | 64.8° | 65.3° | 64.8° | 65.3° | 64.8° | 65.3° | 64.8° |
| Bottom Bracket Height | 341 | 334 | 341 | 334 | 341 | 334 | 341 | 334 |
| Bottom Bracket Drop | 32 | 39 | 32 | 39 | 32 | 39 | 32 | 39 |
| Trail | 124 | 127 | 124 | 127 | 124 | 127 | 124 | 127 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 | 44 | 44 | 44 |
| Chainstay Length | 438 | 440 | 438 | 440 | 438 | 440 | 438 | 440 |
| Wheelbase | 1187 | 1188 | 1216 | 1217 | 1246 | 1247 | 1276 | 1276 |
| Top Tube Length (horizontal) | 572 | 573 | 599 | 600 | 629 | 630 | 656 | 658 |
| Standover Height | 732 | 726 | 733 | 727 | 739 | 733 | 759 | 753 |
| Seat Tube Length | 380 | 380 | 410 | 410 | 435 | 435 | 470 | 470 |
| Seat Tube Angle | 69.3° | 68.8° | 69.8° | 69.3° | 70.8° | 70.3° | 71.3° | 70.8° |
| Effective Seat Tube Angle | 77.3° | 76.8° | 77.3° | 76.8° | 77.3° | 76.8° | 77.3° | 76.8° |
| Wheel size | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
All measurements are in mm unless otherwise stated.
The above table shows the standard geometry for the bicycle as shipped, other geometry configurations may be available with certain bikes. Please contact us via Live Chat to find out more.
